Chauvin Arnoux CA 5275 Multimeter
SKU: 1243
364,00 € without VAT
Specifications
- AC voltage measurement60 mV ... 1000 V
- AC voltage measurement basic accuracy0,1 mV ... 1 V
- DC voltage measurement60 mV ... 1000 V
- DC voltage measurement basic accuracy0,9 % + 2 digits
- AC current measurement6 A ... 10 A
- AC current measurement basic accuracy1.2 % of range + 5 digits
- DC current measurement6 A ... 10 A
- DC current measurement basic accuracy0.2 % range + 2 digits
- Frequency bandwidth for AC voltage and current measurement40 Hz ... 3 kHz
- Resistance measurement600 Ω ... 60 MΩ
- Resistance measurement basic accuracy0,1 Ω ... 0,1 MΩ
- Capacitance measurement6 nF ... 60 mF
- Capacitance measurement basic accuracy2 % range +15 digits
- Frequency measurement600 Hz ... 50 kHz
- Frequency measurment basic accuracy0.1 % range + 2 digits
- Overvoltage categoryCAT IV 600 V and CAT III 1000 V
- Diode testingYes
- Auto-rangingYes
- Acoustic continuity signalingYes
- HOLD functionYes
- ProtectionIP54
- Working temperature-10° C ... 50° C
- Min/Max functionsYes
- Dimmensions90 x 190 x 45 mm
- Weight400 g
