Metrel A 1832 Mode 3 Charging cable adapter is used for electrical safety testing of Mode 3 EV charging cables with Type 2 connectors together with supported METREL or third-party testers. If used together with Metrel AUTOSEQUENCES®, integrated in the newer multifunctional testers, the EV charging cable can be comprehensively tested (including functionally) with a push of a button. It is possible to create a professional report using MESM software.
General data
Charging cable connector: Type 2
Maximum test current: 10 A on test connector / 25 A on banana sockets
Measuring category: 50 V no CAT, max. transient overvoltage 1 100 V
Protection classification: Double insulation
Altitude: 2 000 m
Pollution degree: 2
Protection degree: IP 40
Dimensions: 30 cm x 15 cm x 34 cm
Weight: 3.16 kg
Operation conditions
Working temperature range: 0 °C to +40 °C
Maximum relative humidity: 95 % RH (0 °C to 40 °C), non-condensing
Operation: Outdoor use
