Measurement line type: Single-phase 2-wire, Single-phase 3-wire, Three-phase 3-wire or Three-phase 4-wire plus one extra input channel for voltage, current, power measurement (AC or DC measurement)
Voltage ranges: Voltage measurement: 600.00 V rms, Transient measurement 6.0000 kV peak
Current ranges: 500.00 mA to 5.0000 kA AC (depends on current sensor in use)
Power ranges: 300.00 W to 3.0000 MW (determined automatically based on voltage and current range in use)
Basic accuracy:
Voltage: ±0.1% of nominal voltage
Current: ±0.1 % rdg. ±0.1 % f.s. + current sensor accuracy
Active power: ±0.2 % rdg. ±0.1 % f.s. + current sensor accuracy
Measurement items:
Transient voltage : 2 MHz sampling
Frequency cycle : Calculated as one cycle, 40 to 70 Hz
Voltage (1/2) RMS: one cycle calculation refreshed every half cycle, Current (1/2) RMS: half-cycle calculation
Voltage swell, Voltage dips, Voltage interruption
Inrush current
Voltage waveform comparison
Instantaneous flicker value: As per IEC61000-4-15
200 ms frequency: Calculated as 10 or 12 cycles,40 to 70 Hz
10 sec frequency: Calculated as the whole-cycle time during the specified 10 s period, 40 to 70 Hz
Voltage waveform peak, Current waveform peak
Voltage, Current, Active power, Apparent power, Reactive power, Active energy, Reactive energy, Power factor, Displacement power factor, Voltage unbalance factor, Current unbalance factor, and efficiency
High-order harmonic component (voltage/ current): 2 kHz to 80 kHz
Harmonic/ Harmonic phase angle (voltage/ current), Harmonic power: 0th to 50 th orders
Harmonic voltage-current phase angle: 1th to 50 th orders
Total harmonic distortion factor (voltage/ current)
Inter harmonic (voltage/ current): 0.5 th to 49.5 th order
K Factor (multiplication factor)
IEC Flicker, Δ V10 Flicker
Record: Repeated ON: 1 year, Maximum recording event: 9999 × 366 days (up to 9999 events per day), Repeated off: 35 days, maximum recording event: 9999 events
Interfaces: SD/SDHC memory card, LAN (HTTP server function / FTP function), USB2.0 (for communication)
Display: 6.5-inch TFT color LCD (640 × 480 dots)
Power supply: AC adapter, Battery pack
Continuous use: 180 minutes
Charging time: Max. 5 hr 30 m with AC adapter
Dimensions: 300 x 211 x 68 mm
Weight: 2.5 kg
Standard set: Instruction manual, Measurement guide, Voltage Cord set, Color clip, AC Adapter, Strap, USB cable, Battery pack, SD Memory Card 2GB, Application software (PQ ONE), AC FLEXIBLE CURRENT SENSOR CT7045 (×4).
