Standard set: Teledyne LeCroy Wavesurfer 3054z, 10 Passive Probe (Total of 1 Per Channel), 1 Micro SD card, Micro SD card adapter, Protective Front Cover, Getting Started Guide, Commercial NIST Traceable Calibration with Certificate, Power Cable, 3-year Warranty.
Teledyne Lecroy WaveSurfer 3054z Oscilloscope
SKU: 2834
Specifications
- 310 MHz ... 550 MHz bandwidthYes
- Bandwidth500 MHz
- 8 bit vertical resolutionYes
- ≥ 4 channelsYes
- Sensitivity1 mV/div ... 10 V/div
- Time base1 ns/div ... 100 s/div
- Sample rateup to 4 GS/s
- Channel memory20 Mpts
- Display1 024 x 600 pixels, 10 inch
- Touch screenYes
- InterfacesEthernet, USB, DB-15
