Tonghui TH2829 series automatic component analyzer is completely appropriate for test requirements of all kinds of industrial and military standards.
Standard set: LCR meter, user manual, power cord, test leads
Tonghui TH2829B LCR analyzer
SKU: 785
Specifications
- LCD7" color TFT LCD
- Basic accuracy0,05 %
- Inductance range0,00001 μH ... 99,9999 kH
- Capacitance range0,00001 pF ... 9,99999 F
- Resistance range0,00001 Ω ... 99,9999 MΩ
- Test signal level5 mV ... 10 V RMS
- Test frequency20 Hz ... 500 kHz
- Test parameters|Z|, |Y|, C, L, X, B, R, G, D, Q, θ, DCR, Vdc-Idc
- interfaceUSB, RS232C, LAN, USB HOST
